Extract Dimension Hierarchy Metadata XML Through DM and Extender BR

Imports System
Imports System.Data
Imports System.Data.Common
Imports System.IO
Imports System.Collections.Generic
Imports System.Globalization
Imports System.Linq
Imports Microsoft.VisualBasic
Imports System.Windows.Forms
Imports OneStream.Shared.Common
Imports OneStream.Shared.Wcf
Imports OneStream.Shared.Engine
Imports OneStream.Shared.Database
Imports OneStream.Stage.Engine
Imports OneStream.Stage.Database
Imports OneStream.Finance.Engine
Imports OneStream.Finance.Database

Namespace OneStream.BusinessRule.Extender.XFR_ExportAppTypes

	Public Class MainClass

		'------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
		'Reference Code: XFR_ExportAppTypes
		'
		'Description:                   Executes application extracts and produces XML file.
		'                                         This can be run for different extract types like Metadata or CubeViews
		'                                         The file is written to the application Data Mgmt Export folder in the file share directory.
		'
		'Usage:                             Can be executed from Business Rule editor or run as part of a Data Management sequence.
		'
		'Created By:                    Peter Fu
		'
		'Date Created:                06-05-2021
		'------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
		Public Function Main(ByVal si As SessionInfo, ByVal globals As BRGlobals, ByVal api As Object, ByVal args As ExtenderArgs) As Object
			Try
				Select Case args.FunctionType
					Case Is = ExtenderFunctionType.ExecuteDataMgmtBusinessRuleStep
						'Get Configuration Settings
						Dim configSettings As AppServerConfigSettings = AppServerConfig.GetSettings(si)
						'Data Management extract location
						Dim folderPath As String = FileShareFolderHelper.GetDataManagementExportUsernameFolderForApp(si, True, configSettings.FileShareRootFolder,
						 si.AppToken.AppName
						 ) & "\" & DateTime.UtcNow.ToString("yyyyMMdd") & "\Extracts"  'If the directory does not exist create
If Not Directory.Exists(folderPath) Then Directory.CreateDirectory(folderPath)
						'Full path and file name for extract
						Dim filePath As String = folderPath & "\MetadataEntity " & DateTime.UtcNow.ToString("yyyyMMdd") & ".xml"
						'If file already exist
						If File.Exists(filePath) Then File.Delete(filePath)
						'Extract Options
						Dim xmlOptions As New XmlExtractOptions
						xmlOptions.ExtractAllItems = False
						'Extract dimensions
						Dim extractDict As New Dictionary(Of XmlExtractItemPk, Boolean)
						extractDict.Add(New XmlExtractItemPk(XmlExtractItemType.Dimensions), True)
						'Extract Houston Entities
						Dim dimID As Integer = BRApi.Finance.Dim.GetDimPk(si, "HoustonEntities").DimId
						extractDict.Add(New XmlExtractItemPk(XmlExtractItemType.Dimension, dimID), True)
						'Execute the Metadata Extract
						Using dbConnFW As DbConnInfo = BRApi.Database.CreateFrameworkDbConnInfo(si)
							Using dbConnApp As DbConnInfo = BRApi.Database.CreateApplicationDbConnInfo(si)
								'Extract XML metadata to target location
								File.WriteAllText(filePath, MetadataExtract.ExtractXml(dbConnFW, dbConnApp, xmlOptions, extractDict))
							End Using
						End Using

				End Select

				Return Nothing
			Catch ex As Exception
				Throw ErrorHandler.LogWrite(si, New XFException(si, ex))
			End Try
		End Function
	End Class
End Namespace
